Aircol 150C MP

Ultra-light mechanical back shutter opens with the suction of the air and automatically closes by its own weight when the fan is switched off.
Provides optimum protection against external factors such as dust, malodor or cold when the fan is not operated thanks to the automatic back shutter.
An indispensable part of decorative places with its elegant front view.
Provides the highest possible protection against external factors such as malodors and moisture, and maintains its initial appearance thanks to the high-quality ABS plastic material used.
Front cover can be easily cleaned by being rubbed off.
Minimum sound level thanks to the optimum motor and body design.
Self lubricating motor bearings offer a silent and long-life performance.
The equipment can be vertically installed on windows.
Class-II protection which does not require earth connection.
IPX4 protection against water splash.
All products are manufactured in accordance with the EN 60335-2-80, Low Voltage Equipment [2014/35/EU] and Electromagnetic Compatibility [2014/30/EU] norms.

Fields of Use

Small and medium sized places:
Suitable for ventilation of bathrooms, toilets, kitchens, storerooms, laundry rooms, garages, workplaces, etc.
Suitable especially for direct installation to windows.

OPTIONS OF USE

	Can be directly controlled with an on-off button, or operate in parallel connection to a lamp.
	The fan can be provided to continue to operate for a certain length of time after being switched off, by use of a time delay electronic card.
	Thermal protection with sensors against overheating in hot places.
	Special production for the ambience of the place with various color options.

MODEL	A	B	C	D	E	F	G
AIRCOL – 150C MP	213	156	162,38	44,5	11,5	10	40

Installation on Glazing

Installation on Wall
