Aircol 300 MS

Body and propeller which is produced by galvanized steel sheet and electrostatic paint coated, is resistant to erosion, heat and humid environments.
Generating minimum level of vibration, the product successfully passed the tests performed in compliance with the ISO 1940 standard.
Thanks to its chrome plated wire cage protection on its back side, it is protected against external factors.
With its optimum body and propeller design, more pressure can be obtained at the same flow rate level while sound level is minimized.
The equipment can be horizontally or vertically installed on walls, metal sheets, windows, etc. with ease.
Suitable for different sized places thanks to three models with different dimensions.
The product offers IPX4 protection.
Low energy consumption and high efficiency thanks to the external rotor mono-phase motor.
Roller engine bearings provide maintenance-free, silent and long life performance.
Motor included in IP44 protection class and F insulation class.
All products are manufactured in accordance with the EN 60335-2-80, Low Voltage Equipment [2014/35/EU] and Electromagnetic Compatibility [2014/30/EU] norms.

Fields of Use

For various sized places:
Suitable for ventilation of factories, workshop, paint shops, storehouses, garages, greenhouses, closed animal houses, etc.
Designed especially for direct installation in order to discharge polluted air and provide fresh air.

OPTIONS OF USE

	Standard use with the on-off button.
	Possibility to use at desired speed by use of speed control devices.
	Thermal protection with sensors against overheating in hot places.

MODEL	A	B	C	D	E
AIRCOL 300 MS	300,5	381	71	91	48

Installation to Wall

Create a hole of Ø305 mm for 300 MS on the installation surface.
Create four Ø6 mm dowel holes on the installation surface for the corners of the fan and place the dowels in the holes.
Install the fan in the hole as seen in the figure and fasten by use ofM4 screws.

Installation to Metal Sheet

Create a hole of Ø305 mm for 300 MS on the metal sheet.
Create four Ø5 mm dowel holes on the installation surface for the corners of the fan.
Place the fan in the hole as seen in the figure.
Fix the fan by fastening M4 screws with the M4 bolts.
