AKS 680-360

Resistant to corrosion, high temperatures and other harsh conditions thanks to the body made of high-quality galvanized steel sheet and the impeller made of aluminum.
Light weight, high air flow and low noise level thanks to the forward inclined, aluminum impeller design with thin blades (Ø60 mm).
Generating minimum level of vibration, the product successfully passed dynamic and static balance tests performed in compliance with the ISO 1940 standard, and able to maintain the same amount of air flow during operation.
The product is custom designed for our customers with a speed range between 1300 and 2200 rpm and desired motor and power input terminal positions.
Low energy consumption and high efficiency thanks to the shaded-pole mono-phase motor.
Self-lubricating motor bearings and flexible silicone housing of the fan provide a silent and long-life performance.
Motor included in the B insulation class.
All products are manufactured in accordance with the EN 60335-2-80, Low Voltage Equipment [2014/35/EU] and Electromagnetic Compatibility [2014/30/EU] norms.

Fields of Use

Suitable for use in any industrial heating or cooling application where air flow is needed.
Designed especially for use on vertical refrigerators, ovens, air curtains, catalytic heaters, natural gas heaters, floor level heaters, hand dryers and similar equipments.

OPTIONS OF USE

	Standard use with the on-off button.
	Possibility to use at desired speed by use of speed control devices.
	Thermal protection with sensors against overheating in hot places.

MODEL	A	B	C	D	E	F
AKS 680-360	25	182	68,8	460,4	470	480
