AKS 80M

Made of high-quality aluminum body and thin electrical steel sheet motor, the product is resistant to corrosion, high temperatures, moisture and external factors like contamination and oils.
Internal-rotor, mono-phase motor operates with low energy consumption and high efficiency.
Can be operated at desired position.
Motor can be produced sintered bushing or ball bearing upon customer request.
Motor included in Class-I protection class.
Motor included in F insulation class.
Custom manufacturing with variable speed and desired technical features are possible.
Motor is protected against overheating thanks to thermal contactor.
All products are manufactured in accordance with the EN 60335-2-80, Low Voltage Equipment [2014/35/EU] and Electromagnetic Compatibility [2014/30/EU] norms.

Fields of Use

Suitable for use in any industrial heating or cooling application where air circulation is needed.
Designed especially for kitchen hoods, air curtains, hand dryers, air conditioners and various ventilation applications (axial and centrifugal fans).

OPTIONS OF USE

	Standard use with the on-off button.
	Possibility to use at desired speed by use of speed control devices.
	Thermal protection with sensors against overheating in hot places.
