Aircol 100 KT

Designed for discharging air outside or transferring it through a short duct. The duct used must be straight and shorter than 1.5 m.
Used for providing air movement against low static pressure in small and medium sized places.
Can be conveniently used with rigid or flexible ducts.
Provides the highest possible protection against external factors such as malodors and moisture, and maintains its initial appearance thanks to the high-quality ABS plastic material used.
Minimum noise level and high pressure air suction thanks to the optimum fan design.
The equipment can be installed on walls, ceilings, windows or in ducts with ease.
Self lubricating motor bearings do not require maintenance and offer a silent, long-life performance.
IPX2 protection against water splash.
Class-II protection which does not require earth connection.
All products are manufactured in accordance with the EN 60335-2-80, Low Voltage Equipment [2014/35/EU] and Electromagnetic Compatibility [2014/30/EU] norms.

Fields of Use

Small and medium sized places:
Suitable for ventilation of bathrooms, toilets, kitchens, storerooms, laundry rooms, garages, workplaces, etc.
Suitable especially for induct ventilation applications and for providing air transfer between rooms.

OPTIONS OF USE

	Can be directly controlled with an on-off button, or operate in parallel connection to a lamp.
	The fan can be provided to continue to operate for a certain length of time after being switched off, by use of a time delay electronic card.
	Thermal protection with sensors against overheating in hot places.

MODEL	A	B	C	D	E	F
AIRCOL 100 KT	100	100	96	58	36	104
