Aircol 250 KF

Resistant to corrosion, high temperatures and other harsh conditions thanks to the body made of high-quality galvanized steel sheet.
High pressure air flow, low noise level and high efficiency thanks to the backward inclined impeller design.
Generating minimum level of vibration, the product successfully passed the tests performed in compliance with the ISO 1940 standard.
Very easy electric connection with the terminal box included in the IP54 protection class.
Installation to any location by the help of the installation apparatus given with the product.
Suitable for use in different size places thanks to different size models.
IPX4 protection against water splash.
Low energy consumption and high efficiency thanks to the external rotor mono-phase motor.
Motor bearings offer a silent and long-life performance without the need of maintenance.
Motor included in the IP44 protection class and F insulation class.
All products are manufactured in accordance with the EN 60335-2-80, Low Voltage Equipment [2014/35/EU] and Electromagnetic Compatibility [2014/30/EU] norms.

Fields of Use

For various sized places:
Suitable for ventilation of residences, offices, public toilets, shopping centers, sports centers, theatres, laboratories, factories, workshops, paint shops, storehouses, garages, etc.
Designed especially for installation via a duct connection in order to discharge polluted air and provide fresh air.

OPTIONS OF USE

	Standard use with the on-off button.
	Possibility to use at desired speed by use of speed control devices.
	Thermal protection with sensors against overheating in hot places.

MODEL	A	B	C	D	E	F	G	H	I	J	K
AIRCOL 250 KF	227	30	248	342	130	225	210,5	170	35,5	14	6,5

Create two holes of Ø8 mm on the installation surface, with a distance of 170 mm between them.
After placing the dowels given with the product in the holes, fasten them in a certain amount by use of a wrench or screwdriver as seen in the figure.
As seen in the figure, place the installation foot of the fan in the screw housing you prepared and slide it downwards.
Fully fasten the screws in order to complete installation.
Lastly, install the induct duct to the induct fan by use of installation brackets.
